Product info
-
Technical data
DN: 06 Size: 04 Inch: 1/4 bending radius [mm]: 45 working pressure [bar]: 450 burst pressure [bar]: 1800 Safety factor: 4:1 Standard ferrule: XVN04 Standard ferrule stainless steel: XP-P5-04VA Static test pressure [bar]: 900 Outer Ø max. [mm]: 14,2 Color cover: black Color inner tube: black Cover: Special-Synthetic rubber, wear resistant Inner tube: Oil resistant synthetic rubber MSHA-Approval: no Media: water and water-based media up to max. +70 ° C; Hydraulic oil based on mineral oil and water emulsions and aqueous glycol solutions Norm/Standards: EXCEEDS EN 857 - 2SC Reinforcement: steel wire braids, optimized quality with high tensile strength Temperature range [°C]: -40 ° C to +100 ° C, water and water-based media up to max. +70 ° C; Hydraulic oil based on mineral oil and water emulsions and aqueous glycol solutions application: high pressure applications max operating temperature [°C]: +100°C number of layers: 2
