Product info
-
Technical data
DN: 06 Size: 04 Inch: 1/4 Outer Ø [mm]: 14,4 Inner Ø [mm]: 6,4 bending radius [mm]: 45 working pressure [bar]: 145 burst pressure [bar]: 630 Safety factor: 4:1 Standard ferrule: XVTE04 Weight [kg]: 0,165 Static test pressure [bar]: 290 Outer Ø max. [mm]: 15,2 Color cover: black Color inner tube: black Cover: Synthetic rubber, wear resistant Inner tube: Synthetic rubber MSHA-Approval: no Media: water and water-based media up to + 70 ° C; Hydraulic oil based on mineral oil and water emulsions and aqueous glycol solutions Norm/Standards: EN 854 - 3 TE Reinforcement: Textile braid, double layer Temperature range [°C]: - 40 ° C to + 100 ° C max operating temperature [°C]: +100°C number of layers: 2
