Product info
-
Technical data
DN: 08 Size: 05 Inch: 5/16 bending radius [mm]: 115 working pressure [bar]: 215 burst pressure [bar]: 850 Safety factor: 4:1 Standard ferrule: VC2-05 Static test pressure [bar]: 430 Vacuum [bar]: -0,8 Inner diameter min [mm]: 7,7 Outer Ø max. [mm]: 15,7 Inner diameter max [mm]: 8,5 Color cover: black Color inner tube: black Cover: Synthetic rubber, wear resistant Inner tube: Synthetic rubber MSHA-Approval: no Media: Hydraulic oil based on mineral oil and water emulsions and aqueous glycol solutions Norm/Standards: EN 853 - 1SN Reinforcement: High tensile steel wire Temperature range [°C]: -40 °C to + 100 °C, water and water-based media up to + 70 °C application: medium pressure applications max operating temperature [°C]: +100°C number of layers: 1
