HNV 38 GAS M
Faster HNV-Plug

Product info

• Technical data

  Size:	2
  DN:	10
  Size:	06
  Inch:	3/8
  working pressure [bar]:	300
  Thread + standard:	BSP female-thread ISO 1179-1
  Thread [GA]:	3/8
  Outer Ø plug [mm]:	19,0
  Length plug [mm]:	39,0
  SW [mm]:	22
  SW1 [mm]:	22
  l/min at ΔP=2 bar:	50
  Applications:	Industrial, Oil & Gas
  Female or male coupling:	Plug
  Material Casing:	Steel
  Material sealing:	NBR
  Resistance against red rust [h]:	500
  Standard:	ISO 7241-1B
  Surface:	Mate 500 (Chrom III)
  Temperature range [°C]:	-25 °C to 125 °C
