Product info
-
Technical data
DN: 12 Size: 8 Inch: 1/2 working pressure [bar]: 300 Thread + standard: BSP internal thread for threaded studs DIN 3852-2 / BSP internal thread for threaded studs DIN 3852-2 Thread [G1]: G 1/2 Thread [G2]: G 1/2 L [mm]: 92 Free passage [cm²]: 1,13 Diameter [mm]: 35 Bearing: plain bearing Material Casing: machining steel (9SMn28K) Material axle: nickel Material sealing: NBR/PTFE Media: oil Note: We recommend to filter the medium constantly to an impurity of about 15- 20 µm. Please contact us for alternative threads or materials. Rounds per minute [U/min]: Swivel & very slow rotation Surface: nickel-plated Temperature range [°C]: -30 °C / +95 °C
