STSK-VV08BSP12M

Product info

• Technical data

  Size:	3
  DN:	12
  Size:	08
  Inch:	1/2
  working pressure [bar]:	300
  Thread + standard:	F BSPP ISO 1179-1
  Thread [GA]:	1/2
  Outer Ø sleeve [mm]:	42,0
  Length sleeve [mm]:	78,7
  SW [mm]:	27
  Wrench size connection side sleeve:	27
  SW2 [mm]:	38
  SW1 [mm]:	27
  SW2 [mm]:	38
  l/min at ΔP=2 bar:	45
  Material:	C-steel, nitrified
  Material support ring:	PTFE
  Product title long:	. Series STSK-VV female coupling
  Product title short:	female coupling
