| Size: | 2 |
| DN: | 10 |
| Size: | 06 |
| Inch: | 3/8 |
| working pressure [bar]: | 300 |
| Thread + standard: | BSP female DIN 3852 |
| Thread [GA]: | 3/8 |
| Outer Ø sleeve [mm]: | 31,5 |
| Length sleeve [mm]: | 56,0 |
| SW [mm]: | 22 |
| Wrench size connection side sleeve: | 22 |
| SW1 [mm]: | 22 |
| l/min at ΔP=2 bar: | 28 |
| Material: | C-steel, nitrified |
| Material support ring: | PTFE |
| Product title long: | Series ST-ANV female coupling. |
| Product title short: | female coupling |
Reserve technical changes.
