RSV-DW-1/2

Product info

• Technical data

  working pressure [bar]:	350
  Thread + standard:	G 1/2"
  Fastening thread:	1/2"
  Weight [kg]:	1,284
  L1 [mm]:	144
  max flow [ltr / min]:	70
  Opening pressure [bar]:	3,5
  H [mm]:	60
  pilot ratio:	1:4
  V1-V2 C1-C2 [GAS - MET]:	G 1/2"
  L [mm]:	80
  S [mm]:	35
  L2 [mm]:	40
  L3 [mm]:	18
