| DN: | 6 |
| working pressure [bar]: | 350 |
| Thread + standard: | BSP |
| L1 [mm]: | 113 |
| Thread [G1]: | 1/4" |
| Thread [G2]: | 1/4" |
| Fastening thread: | 1/4" L |
| Weight [kg]: | 0,612 |
| L1 [mm]: | 106,5 |
| max flow [ltr / min]: | 20 |
| Opening pressure [bar]: | 4 |
| H [mm]: | 40 |
| pilot ratio: | 1:5,5 |
| V1-V2 C1-C2 [GAS - MET]: | G 1/4" L |
| L [mm]: | 64 |
| S [mm]: | 30 |
| L2 [mm]: | 36 |
| L3 [mm]: | 18,5 |
| L4 [mm]: | 8 |
Reserve technical changes.
