HAN17J90S12
DKJ JF

Product info

• Technical data

  DN:	19
  Size:	12
  Inch:	3/4
  Thread + standard:	JIC threaded adapter, 74 ° cone with union nut, UN/UNF thread
  Connection thread A:	1.1/16-12
  X [mm]:	59,1
  L1 [mm]:	114,0
  H [mm]:	57,0
  SW1 [mm]:	32
  Type of nut:	With pin
  Connection name Indunorm:	JF 90°
  Connection type:	DKJ 90°
  Construction form:	90°
  Material:	Free cutting sT-l
  Material:	Free cutting sT-l
  Surface:	Cr3
  Type of fittings:	Multi spiral program HAN fittings (no skive)
