R14JF08
DKJ JF

Product info

• Technical data

  DN:	12
  Size:	08
  Inch:	1/2
  Thread + standard:	JIC threaded adapter, 74 ° cone with union nut, UN / UNF thread
  Connection thread A:	7/8"-14 UNF
  X [mm]:	21,0
  L1 [mm]:	68,6
  SW1 [mm]:	27
  Connection name Indunorm:	JF
  Connection type:	DKJ
  Material:	Free cutting steel
  Resistance against red rust [h]:	144
  Resistance against white rust [h]:	72
  Surface:	zinc plated, chrom 6-free
  Type of fittings:	Reusable series R
