VC12BM12
Valcon® swage fitting AGR BM

Product info

• Technical data

  DN:	19
  Size:	12
  Inch:	3/4"
  Thread + standard:	BSP-threaded adapter, 60°-cone with BSP male thread
  L1 [mm]:	75
  d [mm]:	15,0
  T:	3/4-14
  E [mm]:	32
  C [mm]:	36,0
  L [mm]:	75,0
  Connection name Indunorm:	BM
  Connection type:	AGR
  Construction form:	0°
  Material:	Free cutting steel
  Surface:	CrIII
  Type of fittings:	VC
