Technical data
DN: 10 Size: 06 Inch: 3/8 Outer Ø [mm]: 17,0 Inner Ø [mm]: 9,9 bending radius [mm]: 65 working pressure [bar]: 400 burst pressure [bar]: 1600 Safety factor: 4:1 Standard ferrule: XV06C Standard ferrule stainless steel: XP-P1-06VA Weight [kg]: 0,39 Static test pressure [bar]: 800 Outer Ø max. [mm]: 18,3 Braid diameter [mm]: 14,9 Color cover: black Color inner tube: black Cover: Synthetic rubber, wear resistant Inner tube: Oil resistant synthetic rubber MSHA-Approval: no Media: Hydraulic oil based on mineral oil and water emulsions and aqueous glycol solutions Norm/Standards: EXCEEDS EN 857 - 2SN Reinforcement: High tensile steel wire braid Temperature range [°C]: - 40 ° C to + 100 ° C short-term + 120 ° C; Water and water-based media up to max. + 70 ° C application: High pressure applications max operating temperature [°C]: +100°C number of layers: 2
