Product info
-
Technical data
DN: 19 Size: 12 Inch: 3/4 Outer Ø [mm]: 29,0 Inner Ø [mm]: 19,0 bending radius [mm]: 130 working pressure [bar]: 70 burst pressure [bar]: 330 Safety factor: 4:1 Standard ferrule: XVTE12 Weight [kg]: 0,465 Static test pressure [bar]: 140 Outer Ø max. [mm]: 30,0 Color cover: black Color inner tube: black Cover: Synthetic rubber, wear resistant Inner tube: Synthetic rubber MSHA-Approval: no Media: water and water-based media up to + 70 ° C; Hydraulic oil based on mineral oil and water emulsions and aqueous glycol solutions Norm/Standards: EN 854 - 3 TE Reinforcement: Textile braid, double layer Temperature range [°C]: - 40 ° C to + 100 ° C max operating temperature [°C]: +100°C number of layers: 2
