Product info
-
Technical data
DN: 06 Size: 04 Inch: 1/4 bending radius [mm]: 75 working pressure [bar]: 225 burst pressure [bar]: 900 Safety factor: 4:1 Standard ferrule: VC2-04 Weight [kg]: 0,18 Static test pressure [bar]: 450 Braid diameter max [mm]: 10,8 Inner diameter min [mm]: 6,1 Braid diameter min [mm]: 9,6 Outer Ø max. [mm]: max. 13,5 Inner diameter max [mm]: 6,9 Color cover: black Color inner tube: black Cover: Synthetic rubber, wear resistant Inner tube: Synthetic rubber MSHA-Approval: no Media: Hydraulic oil based on mineral oil and water emulsions and aqueous glycol solutions Norm/Standards: EN 857 - 1SC Reinforcement: High tensile steel wire Temperature range [°C]: -40 °C to + 100 °C, water and water-based media up to + 70 °C application: medium pressure applications max operating temperature [°C]: +100°C number of layers: 1
