R4-63 - Textile suction hose R4 | Indunorm Hydraulik Shop

Product info

DN:	63
Size:	40
Inch:	2.1/2
Outer Ø [mm]:	76,5
Inner Ø [mm]:	63,5
bending radius [mm]:	250
working pressure [bar]:	5
burst pressure [bar]:	20
Safety factor:	4:1
Standard ferrule:	-
Weight [kg]:	1,90
Static test pressure [bar]:	10
Vacuum [bar]:	-0,9bar
Approvals:	SAE J517 Type: SAE 100/R4: 2008
Color cover:	black
Color inner tube:	black
Cover:	Synthetic rubber, wear resistant
Inner tube:	Inner tube made of synthetic rubber
MSHA-Approval:	no
Media:	Hydraulic fluids HL + HLP according to DIN 51524
Norm/Standards:	SAE 100 R4
Reinforcement:	Textile wrapped, zinc plated double sT-l wire helix
Temperature range [°C]:	- 40 ° C to + 100 ° C
application:	suction and discharge hose according to SAE 100 R4
max operating temperature [°C]:	+100°C
number of layers:	2

Benefit

Matched fittings and ferrules available to ensure safe connection.

Practical tip

Cutting the hose by means of a hand saw is most suitable. The spring sT-l spiral can eg. to be separated by a power cutters. Prevent injuries by disconnecting protruding ends of the spiral flush. The R4-hose may be cut in any case with a toothed circular blade! With a serrated circular blade there is a risk that the spring sT-l spiral gets stuck in the T-th of the circular knife, which not only damaged the knife but can result in significant injury to personnel. When using a smooth circular k

Reserve technical changes.
