Product info
-
Specifications
DN: 12/19 Size: 8/12 working pressure [bar]: 460 Thread + standard: BSP female ISO 1179-1 Thread [GA]: G1/2"-14; G3/4"-14 Number of hydraulic inserts: 4 Series: 2P Manufacturer ID number: PH510-4-A F C max. number of hydraulic plugs: 4 l/min at ΔP=2 bar: DN 12: 60; DN19: 105 Designation: sleeve Female or male coupling: female Resistance against red rust [h]: 1000 Surface: MATE 1000 (ZnNi)
