| Size: | 4 |
| DN: | 20 |
| Size: | 12 |
| Inch: | 3/4 |
| working pressure [bar]: | 360 |
| Thread + standard: | BSP female DIN 3852 |
| Thread [GA]: | 3/4 |
| Outer Ø plug [mm]: | 115,0 |
| Length plug [mm]: | 78,0 |
| Wrench size connection side plug: | 46 |
| burst pressure plug uncoupled [bar]: | 1100 |
| SW1 [mm]: | 33 |
| burst pressure sleeve uncoupled [bar]: | 1300 |
| l/min at ΔP=2 bar: | 106 |
| L1 [mm]: | 132,5 |
| Material: | steel |
| Material support ring: | PTFE |
Reserve technical changes.
