Banjo angle union WHO/body (inch)

Detail

working pressure [bar]
400
400
400
250
250
250
315
315
315
burst pressure [bar]
1600
1600
1600
1000
1000
1000
1260
1260
1260
Pipe Ø R [mm]
12
16
20
25
30
38
12
12
15
Thread [G1]
M20x1,5
M24x1,5
M30x2
M36x2
M42x2
M52x2
M18x1,5
M18x1,5
M22x1,5
Thread [G2]
G 3/8"
G 1/2"
G 3/4"
G 1"
G 1.1/4"
G 1.1/2"
G 3/8"
G 1/2"
G 1/2"
Series
S
S
S
S
S
S
L
L
L
SW1 [mm]
30
36
41
50
60
70
30
30
36
SW2 [mm]
24
27
32
41
50
55
24
24
27
Quantity


Product info

  • Technical data
    Connection type 1: Metric 24°
    Connection type 2: Imperial
    Construction form: Angle 90°
    Description: High pressure angle swivel fitting
    Material: ST-l
    Resistance against red rust [h]: 1000
    Resistance against white rust [h]: 500
    Surface: zinc plated, chrom 6-free
