Product info
-
Technical data
DN: 19 Size: 12 Inch: 3/4 Outer Ø [mm]: 27,5 Inner Ø [mm]: 19,5 bending radius [mm]: 200 working pressure [bar]: 235 burst pressure [bar]: 940 Safety factor: 4:1 Weight [kg]: 0,81 Static test pressure [bar]: 470 Braid diameter [mm]: 25,6 Color cover: black Color inner tube: black Cover: Synthetic rubber with UHMPE film, no abrasion Inner tube: Synthetic rubber MSHA-Approval: yes Media: Hydraulic oil based on mineral oil, oil and water emulsions and aqueous glycol solutions Norm/Standards: EN 857 - 2SC Reinforcement: high tensile steel wire braid Temperature range [°C]: - 40 ° C to + 100 ° C, water and water-based media up to max. + 70 ° C application: high pressure applications max operating temperature [°C]: +100°C number of layers: 2
