MST-PB06-2-08BSP10M
Multi coupling series MST-PB

Product info

• Technical data

  DN:	10
  Size:	06
  working pressure [bar]:	250
  Thread + standard:	BSP female-thread ISO 1179-1
  Thread [GA]:	1/2"
  Number of hydraulic inserts:	2
  Series:	2P
  Manufacturer ID number:	2PB06-2-12G FC
  max. number of hydraulic plugs:	2
  l/min at ΔP=2 bar:	40
  Applications:	industry, agricultural technology , power units, construction machines
  Female or male coupling:	Sleeve
  Material:	Aluminium & Steel
  Material sealing:	NBR & PUR
  Maximum assignment of the multi-coupling:	2
  Note:	Multi coupling, Flat Face, few leakage oil, allows the connection of several hydraulic lines simultaneously. Connection allowed up to 60bar residual pressure (2P) and full working pressure in the 3P version.
  Resistance against red rust [h]:	500
  Surface:	MATE 500 (CrIII)
  Temperature range [°C]:	-25°C / +100°C
