FB 24/112NPT F5
Faster FB-Sleeve

Product info

• Technical data

  DN:	38
  Size:	24
  working pressure [bar]:	200
  Thread + standard:	NPT female-thread ANSI B1.20.3
  Thread [GA]:	1.1/2"
  Outer Ø sleeve [mm]:	150,0
  Length sleeve [mm]:	110,2
  SW1 [mm]:	50
  l/min at ΔP=2 bar:	300
  Applications:	road machines applications
  Female or male coupling:	Sleeve
  Material Casing:	Brass
  Material sealing:	NBR
  Temperature range [°C]:	-25 °C to 125 °C
