1SN08
Braided hose 1SN

Product info

• Technical data

  DN:	08
  Size:	05
  Inch:	5/16
  Outer Ø [mm]:	14,7
  Inner Ø [mm]:	8,3
  bending radius [mm]:	115
  working pressure [bar]:	215
  burst pressure [bar]:	860
  Safety factor:	4:1
  Standard ferrule:	XVN05
  Standard ferrule stainless steel:	XP-P5-05VA
  Weight [kg]:	0,220
  Static test pressure [bar]:	430
  Outer Ø max. [mm]:	15,0
  Braid diameter [mm]:	12,5
  Color cover:	black
  Color inner tube:	black
  Cover:	Synthetic rubber, wear resistant
  Inner tube:	Synthetic rubber
  MSHA-Approval:	no
  Media:	Hydraulic oil based on mineral oil and water emulsions and aqueous glycol solutions
  Norm/Standards:	EN 853 - 1SN
  Reinforcement:	1 layer of high tensile steel wire
  Temperature range [°C]:	- 40 ° C to + 100 ° C
  application:	high pressure applications
  max operating temperature [°C]:	+100°C
  number of layers:	1
