R15-32
Spiral hose R15

Product info

• Technical data

  DN:	31
  Size:	20
  Inch:	1.1/4
  Outer Ø [mm]:	49,8
  Inner Ø [mm]:	32,0
  bending radius [mm]:	445
  working pressure [bar]:	420
  burst pressure [bar]:	1680
  Safety factor:	4:1
  Standard ferrule:	HVR20
  Weight [kg]:	2,48
  Static test pressure [bar]:	840
  Color cover:	black
  Color inner tube:	black
  Cover:	Synthetic rubber, wear resistant
  Inner tube:	Synthetic rubber
  MSHA-Approval:	no
  Media:	Hydraulic oil based on mineral oil and water emulsions and aqueous glycol solutions
  Norm/Standards:	SAE 100 R15
  Reinforcement:	high tensile steel spirals
  Temperature range [°C]:	- 40 ° C to + 120 ° C, water and water-based media up to max. + 70 ° C
  application:	High pressure applications
  max operating temperature [°C]:	+120°C
  number of layers:	DN19-24 = 4, DN31-38 = 6
